PJ-763

A4 mobile printer with Bluetooth connectivity

PJ-763
PJ-763 2
PJ-763 3

651,79 € Inc. VAT

Find a local store

Built-in Bluetooth and USB connectivity

High-resolution 300dpi thermal print technology

Up to 8ppm print speed

Product Details

PJ763_main

Android, Windows, Mac, Linux and Citrix support

Optional high-capacity Li-ion battery for printing away from power sources

Customise your print solution with vehicle mounting kit, chargers and protective cases

Key Features

  • Built-in Bluetooth and USB connectivity
  • High-resolution 300dpi thermal print technology
  • Up to 8ppm print speed
  • Android, Windows, Mac, Linux and Citrix support
  • Optional high-capacity Li-ion battery for printing away from power sources
  • Customise your print solution with vehicle mounting kit, chargers and protective cases

About Product:

Print quotations, invoices, and other reports whilst on the move and streamline the work of field sales, field service, logistics, delivery and the emergency service sectors.

The PJ-763 with built-in Bluetooth and USB connectivity offers a mobile A4 print solution compact enough to fit easily into a briefcase or computer bag, but that can also be permanently installed in vehicles.

Thermal print technology at 300dpi produces crisp text at a print speed of up to 8 pages per minute.

Compatible with a wide range of mobile and desktop operating systems, the PJ-763 can easily be integrated into your own apps and software using the various SDK's (Software Development Kits) available.

Compatible with

Specifications More about this product...

Specifications

General - Printers

Printer type Mono
Barcode symbologies Linear: Code39, Code93, Code128, ITF, UPC-A/E, EAN-8/13, GS1-128 (UCC/EAN-128), GS1 DataBar (RSS), MSI, Industrial 2of5, Postnet. 2D:PDF417/MicroPDF417, DataMatrix, Maxicode, QR Code/Micro QR Code, Aztec
Max paper size A4
Memory RAM: 32MB, Flash: 6MB

Connectivity

Bluetooth Ver 2.1 EDR
Bluetooth profiles SPP, BIP, OPP and HRCP
USB interface Ver.2.0 (Full Speed). Peripheral plug type: Mini-B

Mobile connectivity

Supported Android SDK (Android ver 2.3 or later using Bluetooth, ver 3.1 or later using USB connection)

Dimensions & weights

Dimensions 255(W) x 55(D) x 30(H) mm
Weight 480 g

In the box

Contents PJ-763 mobile printer, USB Cable, Printhead Cleaning Sheet, Documentation

Media specifications

Weights Min: 105mm x 25.4mm, Max: 216mm x 5.49metres

Operating systems & software

Supported Windows - Vista/7/8/8.1/10/Server 2008/Server 2008 R2/Server 2012/Server 2012 R2, Mac OSX - v10.8/10.9/10.10, Linux - Redhat, Debian

Printing

A4 standard print speed Up to 8 pages per minute
Resolution 300x300dpi
Bitmap fonts Helsinki, Brussels, Letter Gothic Bold
Emulations ESC/P-P, ESC/P_B, Raster_P, P-touch Template
Outline/Vector fonts Helsinki, Brussels, Letter Gothic

Solutions

Supported iPrint & Scan, P-touch Editor, P-touch Transfer Manager, Citrix Xen App/Xen Desktop/Citrix Ready Certification (Windows only)

Warranty

Warranty 1 year return to base
Show more +
Show Less -

Support and downloads

woman sat at a desk on a laptop

Downloads & Drivers

Download and install the latest drivers and software for your Brother products.

View Downloads
man and a woman sat a desk on a laptop

FAQs

Find the answers to our most frequently asked questions and troubleshooting here.

View FAQs
man sat on a sofa working on a tablet

Manuals & Guides

Download the latest manuals and user guides for your Brother products

View Manuals
Technical Specifications

More about this product...



High quality A4 printing on the move

The Brother PJ range of mobile printers finally offer businesses a reliable way of producing high quality A4 sized prints wherever and whenever they are required. Featuring direct thermal printing, this technology is considered by many to be the only reliable solution for mobile print applications. And as no ink, toner or ribbons are used, this ensures workers don't have to source expensive replacements when they run out - the only consumable used is the paper itself.



Compact and lightweight

Despite its incredibly small size and lightweight design, the development and manufacturing process has been focussed on producing a durable, professional printer that can be carried in a briefcase or computer bag, or permanently mounted in a vehicle.

USB connectivity

Offering the reliability of a wired connection, you can connect to Windows®, Mac or Linux based desktops and laptops, or to Android devices that have USB Host support (requires Android OS ver 3.1 or later).

Integrate printing within your existing mobile apps and software

Enabling printing within existing apps or software used to be a difficult task.

However, as well as standard printer drivers for Windows®, Mac and Linux, Brother has a range of SDK (Software Development Kits) that allow developers to easily add printing capabilities into existing solutions, or allow new printing apps to be developed quickly and efficiently.

SDK's are available for iOS, Android and Windows® operating systems.



For more information, please visit the Brother European Developer website at:

http://www.brother.eu/developers
